2PC Trunnion Ball Valve, API 6D, ASTM A216 WCB, 12 IN, CL150

Home Products Ball Valve Trunnion Mounted Ball Valve 2PC Trunnion Ball Valve, API 6D, ASTM A216 WCB, 12 IN, CL150

Key Specifications / Features

This Trunnion Mounted Ball Valve, manufactured in China, features a two-piece body design and complies with API 6D standards. Made from ASTM A216 WCB material, it is 12 inches (DN300) in size with a Class 150 LB pressure rating and PN20. The valve is equipped with RF flanged ends and is worm gear operated, ensuring smooth and reliable operation for various industrial applications.

Model No.: KV-20241225-TMBV-01
Hits: 160
Categories: Trunnion Mounted Ball Valve
Tags: API 6D Ball Valve , ASTM A216 WCB Ball Valve , Trunnion Mounted Ball Valve

Request a quote

Detail Information

Product Name: Trunnion Mounted Ball Valve, Two Piece Body
Design Standard: API 6D
Body Material: ASTM A216 WCB
Size: 12 Inch, DN300
Pressure: Class 150 LB, PN20
End Connection: RF Flanged
Operation: Worm Gear

KOSEN Trunnion Mounted Ball Valves offer easy and smooth operation under high line pressure. Carefully aligned bearings facilitate low-torque operation. The ball is fixed in position but free to turn. All cast trunnion ball valves manufactured by us feature reliable, high-quality castings and a fire-safe design, certified according to BS 6755, API 607, and API 6FA. They meet all applicable ASME standards.

Our Cast Steel Trunnion Ball Valves are available in two types: Two-Piece Split Body and Three-Piece Bolted Body. They are designed and manufactured to the latest international standards, including API 6D, ASME B16.34, and BS 5351, or their equivalents. Standard features include fire safety, anti-static protection, and stem blow-out proof design.

Technical Specification

» Size Range: NPS 2-48 Inch (DN50-DN1200)
» Design Pressure: Class 150-2500 LB (PN10-PN420)
» Temperature Range: -46°C to 120°C
» Materials: Cast Carbon Steel, Stainless Steel, Duplex, or Other Special Alloys
» Trim Materials: 13% Cr, SS 304, SS 304L, SS 316, SS 316L, and other special alloys
» Seat Materials: RPTFE, DEVLON, PEEK
» End Connections: Flanged (RF, RTJ), Welded
» Operation: Handle, Worm Gear, Electric, Pneumatic
» Design and Manufacture Standards: API 6D, BS 5351, ASME B16.34
» Face to Face (End to End): ASME B16.10
» Flanged Connections: ASME B16.5, ASME B16.47
» Test and Inspection: API 598, API 6D
» Butt Welded Ends: ASME B16.25
» Fire Safety Standards: API 607, API 6A

Product Features

» Double Block And Bleed (DBB)
» Low Operating Torque
» Emergency Sealing Device
» Fireproof Structure Design
» Anti-static Structure
» Reliable seat sealing structure
» Single Sealing (Automatic Pressure Relief In Middle Cavity of Valve)
» Double Sealing (Double Piston)
» Safety Relief Device
» Special Structure of Automatic Pressure Relief Towards Upper Stream
» Blow-out Proof Stem
» Corrosion Resistance and Sulfide Stress Resistance
» Optional Locking Device or Stem Extension
» Optional Direct Mounting to ISO 5211
» Full Port or Reduce Bore
