Key Specifications / Features
The Low Temperature Ball Valve Factory offers cryogenic ball valves that are trunnion mounted, adhering to API 6D standards. These valves feature a 6-inch diameter with a Class 150 LB rating and flanged ends for secure connections. Constructed from stainless steel ASTM A182 F304, they are designed for reliable performance in low-temperature applications, ensuring durability and efficient flow control.
- Model No.: KV-20251210-TMBV-01
- Hits: 1
- Categories: Trunnion Mounted Ball Valve
- Tags: Low Temperature Ball Valve, 6 Inch Ball Valve, ASTM A182 F304 Ball Valve
Detail Information
Product Name: Low Temperature Ball Valve, Cryogenic Ball Valve
Type: Trunnion Mounted Ball Valve
Design Standard: API 6D
Body Material: ASTM A182 F304
Size: 6 Inch, DN150, 150 mm
Pressure: Class 150 LB, PN20
End Connection: Flanged
Operation: Gear
Trunnion-mounted ball valves enable easy, smooth operation even under high line pressure. Precisely aligned bearings support low-torque rotation, while the ball remains fixed in position but free to turn. All cast trunnion ball valves feature high-quality castings and a fire-safe design certified according to BS 6755, API 607, and API 6FA. They meet all applicable ASME standards. Cast steel trunnion ball valves are available in two-piece split-body and three-piece bolted-body designs. They are engineered and manufactured to the latest international standards, including API 6D, ASME B16.34, BS 5351, or their equivalents, and come with standard features such as fire-safe construction, anti-static design, and stem blowout-proof protection.
Technical Specification
» Product: Trunnion Mounted Ball Valve
» Size Ranges: NPS 2–48 Inch (DN50–DN1200)
» Design Pressure: Class 150–2500 LB (PN10–PN420)
» Materials: Cast Carbon Steel, Stainless Steel, Duplex, or Other Specials
» Trim Materials: 13%Cr, SS 304, SS 304L, SS 316, SS 316L, and other specials
» Seat Materials: RPTFE, DEVLON, PEEK
» End Connections: Flanged RF, RTJ, Welded
» Operation: Handle, Worm Gear, Electric, Pneumatic
» Design and Manufacture: API 6D, BS 5351, ASME B16.34
» Face to Face (End to End): ASME B16.10
» Flanged Connection: ASME B16.5, ASME B16.47
» Test and Inspection: API 598, API 6D
» Butt Welded End: ASME B16.25
» Fire Safety: API 607, API 6A
Product Features
» Double Block and Bleed (DBB)
» Low Operating Torque
» Emergency Sealing Device
» Fireproof Structural Design
» Anti-static Structure
» Reliable Seat-Sealing Structure
» Single Sealing (Automatic Pressure Relief in Valve Mid-Cavity)
» Double Sealing (Double Piston Effect)
» Safety Relief Device
» Special Automatic Upstream Pressure-Relief Structure
» Blowout-Proof Stem
» Corrosion Resistance and Sulfide Stress Resistance
» Optional Locking Device or Stem Extension
» Optional ISO 5211 Direct Mounting
» Full Port or Reduced Bore
