Carbon Steel Floating Ball Valves, A216 WCB, 3 IN, CL150 LB

Product Name: Carbon Steel Floating Ball Valves
Type: Floating Ball Valve
Body Material: Carbon Steel, ASTM A216 WCB
Size: 3 Inch, DN80, 80 mm
Pressure: Class 150 LB, PN20
End Connection: RF Flanged
Operation: Lever
Temperature Range: -46°C to 120°C

Cast Floating Ball Valves feature a design in which the ball is supported by two PTFE seats, one on the upstream side and the other on the downstream side. When upstream pressure is applied, it pushes the ball toward the downstream seat, compressing it to achieve a complete and reliable shutoff. All our Cast Floating Ball Valves are manufactured with high-quality castings and include a fire-safe design certified according to BS 6755, API 607, and API 6FA. They meet all applicable ASME standards. Floating Ball Valves are available in One-Piece Uni-body, Two-Piece Split Body, and Three-Piece Bolted Body designs. They are engineered and manufactured to the latest international standards, including API 6D, ASME B16.34, BS 5351, or their equivalents. Standard features include fire-safe construction, anti-static protection, and blowout-proof stem design.

Technical Specification

» Product: Cast Floating Ball Valve
» Size Ranges: NPS 1/2-10 Inch (DN15-DN250)
» Design Pressure: Class 150-600 LB (PN10-PN100)
» Materials: Cast Carbon Steel, Stainless Steel, Duplex, or Other Specials
» Trim Materials: 13%Cr, SS 304, SS 304L, SS 316, SS 316L, and other specials
» Seat Materials: NYLON, RPTFE, PEEK
» Ends Connections: FF and RF flange, Welded
» Operation: Handle, Worm Gear, Electric, Pneumatic
» Design and Manufacture: API 6D, BS 5351, ASME B16.34
» Face to Face (End to End): ASME B16.10
» Flanged Connection: ASME B16.5
» Test and Inspection: API 598, API 6D
» Butt Welded End: ASME B16.25
» Fire Safety: API 607, API 6A

Structural Diagram

Product Features

» Low operating torque
» Emergency sealing device
» Fireproof structural design
» Anti-static structure
» Reliable seat-sealing design
» Special structure for automatic upstream pressure relief
» Blowout-proof stem with flyout-prevention design
» Corrosion resistance and sulfide stress resistance
» Optional locking device or stem extension
» Optional direct mounting to ISO 5211
» Full port or reduced bore options
